KIT, MASTERCOOL, RECYCLE, STAND ALONE UNIT
TO-38820
Description
This Mastercool stand-alone unit is an R134a refrigerant recovery, recycling, and recharging machine designed for automotive A/C systems. It performs automatic or programmable recovery, recycling, vacuum, vacuum leak testing, and recharging procedures. The unit includes a refrigerant capacity database and features automatic oil discharge and air purge functions.
Specifications
| refrigerant type | R134a |
| voltage | Available in 110V / 60 Hz or 220-240V / 50/60 Hz |
| scale resolution | 10g (0.02 lb) |
| vacuum pump | 3 CFM or 6 CFM (100 litre/min) or 75 l/min |
| recovery cylinder | Internally mounted 30 lb. DOT tank or 12 litres, refillable |
| hoses | 96” (250cm) |
| couplers | Manual |
| dimensions | Approx. 102 x 58 x 51 cm (40.25” h x 22.75” w x 20” d) or 55 x 60 x 105 cm |
| weight | Approx. 71 kg (157 lbs) or 80 kg (176 lbs) |
| certifications | SAE J2788 certified design |
Vehicle / Equipment Applications
Automotive A/C servicingCommercial vehicle A/C servicing
Weight: 1.5 kg
